Codice:

TL-CPE710

Marchio:

TP-Link

Garanzia:

Dimensioni:

Peso:

1710

• 802.11ac fino a 867Mbps in 5GHz

• Antenna direttiva ad alto guadagno 23dBi ideale per collegamenti a lunga distanza

• Struttura robusta con assemblaggio rapido a incastro per la massima stabilità anche in condizioni di forte vento

• Certificazione IP65 contro le intemperie, protezione da scariche elettriche 15 kV ESD e 6 kV

• Gestione centralizzata con software gratuito Pharos Control

• Supporto Passive PoE per installazione flessibile.

CARATTERISTICHE HARDWARE
Processore	Qualcomm 750MHz CPU, MIPS 74Kc
Memoria	128 MB DDR2 RAM, 16 MB Flash
Interfaccia	1 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button
Alimentazione	Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27V DC
Dimensioni ( L x P x A )	366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
Guadagno antenna	23 dBi
Ampiezza del diagramma di emissione	9° (Azimuth)/7° (Elevation)
Sicurezza	15 KV ESD Protection 6 KV Lightning Protection
Enclosure	Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design

CARATTERISTICHE WIRELESS
Standard wireless	IEEE 802.11a/n/ac
Velocità wireless	Up to 867 Mbps (80 MHz, Dynamic) Up to 400 Mbps (40 MHz, Dynamic) Up to 173.4 Mbps (20 MHz, Dynamic)
Frequenza	5.15–5.85 GHz
Potenza di trasmissione	Max. 27 dBm (Adjustable power by 1dBm)

CARATTERISTICHE SOFTWARE
Configurazione di rete	WAN: Static/ Dynamic/ PPPoE LAN: Static/ Dynamic/ DHCP Forwarding: ALG/ UPnP/ Virtual Server/ Port Trigger Security: SPI Firewall/ Ping Forbidden/ DoS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding
Configurazioni wireless	Selectable Channel Width: 20/40/80MHz Auto Channel Selection Transmit Power Control Dynamic Frequency Selection(DFS) WDS Enable/ Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, SSID Broadcast Enable/ Disable Multi-SSID with VLAN Tagging(AP Mode only) Distance/ ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: Beacon Interval/ RTS Threshold/ Fragmentation Threshold/ DTIM Interval/ AP Isolation/ Short GI/ Wi-Fi Multimedia Long Range PtP
Gestione	Discovery and Remote Management via Pharos Control application HTTP/ HTTPS Web-based management System log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server
Tool di sistema	Indicators:Signal Strength/ Noise/ Transmit CCQ/ CPU/ Memory Monitors: Throughput/ Stations/ Interfaces/ ARP/ Routes/ WAN/ DHCP Spectrum Analyzer Speed Test Ping Traceroute Antenna Alignment
Ottimizzazioni di sistema	Optimized IGMP Snooping / Proxy for multicast applications

CARATTERISTICHE ADATTATORE POE
Dimensioni ( L x P x A )	85.8×43.9×29.7 mm
Interfacce	1 AC Jack with Earth Ground 1× 10/100/1000 Mbps Shielded Ethernet Port (Power + Data) 1× 10/100/1000 Mbps Shielded Ethernet Port (Data)
Tasto	Remote Reset Button
Indicatori di carica LED	Green
Input	100-240VAC, 50/60Hz
Output	24VDC, 0.5A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Efficienza	>84.29%
Certificazioni	CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark

ALTRO
Certificazione	CE, FCC, RoHS, IP65, IC
Contenuto della confezione	Outdoor Wireless CPE 24V 0.5A Passive PoE Adapter Pole Mounting Kits AC Power Cord Installation Guide
Requisiti di sistema	Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
Ambiente	Operating Temperature: -40â„ƒ~70â„ƒ (-40â„‰~158â„‰) Storage Temperature: -40â„ƒ~70â„ƒ (-40â„‰~158â„‰) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing
